CDR25D07LANP-R68PC datasheet(1/2 Pages) SUMIDA

Part #	CDR25D07LANP-R68PC

Description	Power Inductor

PDF	2 Pages

Scroll/Zoom	100%

Manufacturer	SUMIDA [Sumida Corporation]

Direct Link	http://www.sumida.com

Logo

1 / 2 page

1

■

Features

◎

Magnetically shielded construction.

◎

Storage temperature range: -40

℃

~+105

℃

.

◎

Operating temperature range: -40

℃

~+105

℃

(including coil’s self temperature rise).

◎

H

igh operating frequency up to 6MHz.

◎

RoHS Compliance and Halogen Free.

■

Applications

Ideally used in MP3/MP4, smart phone, PDA, DSC/DVC, etc.

■

Dimensions/Recommended Land Patterns (mm)

Power Inductor

CDR25D07/LA

◆

◆ Dimensions

◆

◆ Land pattern

2.56

2.

56

(3

.2

0)

(2

.4

0)

(1.

15)

45

°

+0.15

-0.10

+0

.1

5

-0

.1

0

MAX 0.80

C0.40

45

°

2.2

0

3.5

0

1.

30

R0.10
