NOTE: All specifications are subject to change without notification.

SCD's for these devices should be reviewed by SSDI prior to release.

DATA SHEET #: RH0023B

DOC

Solid State Devices, Inc.

14701 Firestone Blvd * La Mirada, Ca 90638

Phone: (562) 404-4474 * Fax: (562) 404-1773

ssdi@ssdi-power.com * www.ssdi-power.com

SHF1402 - SHF1406

and

SHF1402SMS - SHF1406SMS

Electrical Characteristics

Symbol

Max

Units

Instantaneous Forward Voltage Drop

(IF = 3 Adc, TA = 25ºC, 300 µs pulse)

1.5

Vdc

Instantaneous Forward Voltage Drop

(IF = 4 Adc, TA = 25ºC, 300 µs pulse)

1.6

Vdc

Reverse Leakage Current

(Rated VR, TA = 25ºC, 300 µs pulse minimum)

μA

Reverse Leakage Current

(Rated VR, TA = 100ºC, 300 µs pulse minimum)

Junction Capacitance

(VR = 10 Vdc, TA = 25ºC, f = 1MHz)

Reverse Recovery Time

(IF = 500 mA, IR = 1A, IRR = 0.25A, TA = 25ºC)

(IF = 500 mA, IR = 1A, IRR = 0.25A, TA = 100ºC)

trr

nsec

Case Outline: (Axial)

ØC

ØA

DIMENSIONS

DIM

MIN

MAX

.140”

.170”

.230”

.047”

.053”

1.00”

---

Case Outline: (SMS)

DIMENSIONS

DIM

MIN

MAX

.172”

.180”

.220”

.270”

.022”

.028”

.002”

---
