1 / 6 page  UNISONIC TECHNOLOGIES CO., LTD 3422 LINEAR INTEGRATED CIRCUIT www.unisonic.com.tw 1 of 6 Copyright © 2011 Unisonic Technologies Co., LTD QW-R105-029,Ba HIGH PERFORMANCE DUAL BIPOLAR OPERATINAL AMPLIFIER DESCRIPTION The UTC 3422 is a dual high performances operational amplifier featuring speed of 25MHz and single supply operation from 3V ~ 36V. The UTC 3422 is therefore an enhanced replacement of standard dual operational amplifiers. FEATURES * Single Supply Operation: 3V ~ 36V * Dual Supply Operation: ±1.5V ~ ±18V * High Gain Bandwidth Product: 25MHz * High Slew Rate: 15V/μs * Low Voltage Noise: 14nV/√Hz * No Phase Inversion * ESD Tolerance: 2KV * Latch-Up Immunity DIP-8 SOP-8 ORDERING INFORMATION Ordering Number Lead Free Halogen Free Package Packing 3422L-D08-T 3422G-D08-T DIP-8 Tube 3422L-S08-R 3422G-S08-R SOP-8 Tape Reel 3422L-S08-T 3422G-S08-T SOP-8 Tube |
