2 / 5 page ![]() UT2306 Power MOSFET UNISONICTECHNOLOGIESCO.,LTD 2 of 5 www.unisonic.com.tw QW-R502-130.C ABSOLUTE MAXIMUM RATINGS (Ta = 25℃, unless otherwise specified) PARAMETER SYMBOL RATINGS UNIT Drain-Source Voltage VDSS 30 V Gate-Source Voltage VGSS ±8 V Continuous Drain Current ID 3.5 A Pulsed Drain Current (Note 1, 2) IDM 14 A Power Dissipation PD 0.83 W Junction Temperature TJ +150 ℃ Storage Temperature TSTG -55 ~ +150 °C Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied. THERMAL DATA PARAMETER SYMBOL MIN TYP MAX UNIT Junction-to-Ambient θJA 150 °C/W ELECTRICAL CHARACTERISTICS (Ta =25°C, unless otherwise specified) PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT OFF CHARACTERISTICS Drain-Source Breakdown Voltage BVDSS VGS=0V, ID=250μA 30 V Drain-Source Leakage Current IDSS VDS=24V, VGS=0V 1 μA Gate-Source Leakage Current IGSS VDS=0V, VGS=±20V ±100 nA ON CHARACTERISTICS Gate Threshold Voltage VGS(TH) VDS=VGS, ID=250μA 1 1.5 2 V VGS=10V, ID=3.5A 42 65 mΩ Drain-Source On-State Resistance (Note 2) RDS(ON) VGS=5V, ID=2.8A 70 90 mΩ DYNAMIC CHARACTERISTICS Input Capacitance CISS 400 pF Output Capacitance COSS 80 pF Reverse Transfer Capacitance CRSS VDS=25V,VGS=0V, f=1.0MHz 45 pF SWITCHING CHARACTERISTICS Turn-ON Delay Time tD(ON) 10 19 ns Turn-ON Rise Time tR 8 15 ns Turn-OFF Delay Time tD(OFF) 19 35 ns Turn-OFF Fall Time tF VDD=15V, VGS=10V, ID=1A, RG=6Ω, RL=15Ω 6.2 12 ns Total Gate Charge QG 12.5 16 nC Gate-Source Charge QGS 2.4 nC Gate-Drain Charge QGD VDS=15V, VGS=10V, ID=3.5A 1.3 nC SOURCE-DRAIN DIODE RATINGS AND CHARACTERISTICS Drain-Source Diode Forward Voltage(Note2) VSD VGS=0V, IS=1.25A 0.8 1.3 V Maximum Continuous Drain-Source Diode Forward Current IS 1.3 A Note:1. Pulse width limited by TJ(MAX) 2. Pulse width ≤300us, duty cycle ≤2%. 3. Surface mounted on FR4 board t≦10sec. |
|
|
