4 / 17 page ![]() LR1106 CMOS IC UNISONICTECHNOLOGIESCO.,LTD 4 of 17 www.unisonic.com.tw QW-R502-055,Q ABSOLUTE MAXIMUM RATINGS (TA=25°С, unless otherwise specified) PARAMETER SYMBOL RATINGS UNIT Input Voltage VIN 8 V Output Voltage VOUT VSS -0.3 ~ VIN+0.3 V Output Current IOUT 400 mA Power Dissipation SOT-25/SOT-23 PD 300 mW SOT-89/SOP-8 500 mW VSON-6 1000 mW Operating Ambient Temperature TOPR -40 ~ +85 °С Storage Temperature TSTG -40 ~ +125 °С Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied. ELECTRICAL CHARACTERISTICS (TA=25°С, unless otherwise specified.) For LR1106-18 PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT Output Voltage VOUT VIN=2.8V, IOUT=40mA 1.764 1.800 1.836 V Input Voltage VIN 8 V Load Regulation ΔVOUT VIN=2.8V, 1mA≤IOUT≤200mA 40 100 mV Dropout Voltage VD1 IOUT=100mA 200 300 mV VD2 IOUT=200mA 400 600 Maximum Output Current IOUT(MAX) VIN=2.8V, VOUT≥VOUT× 0.90 400 mA Supply Current ISS VIN=2.8V, VEN=VIN 30.0 50.0 μA EN Input Bias Current IEH VEN=VIN 0.1 μA IEL VEN=0, VIN=2.8V to 8V 1.0 3.0 μA EN Input Threshold VEH VIN=2.8V to 8V VIN/2+0.8 VIN V VEL VIN=2.8V to 8V 0 0.4 V Line Regulation V △ OUT V △ IN×VOUT IOUT=40mA, 2.8V≤VIN≤8.0V 0.2 0.5 %/V Output Voltage Temperature Characteristics V △ OUT T △ OPR×VOUT IOUT=40mA ±100 ppm/°С For LR1106-22 PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT Output Voltage VOUT VIN=3.2V, IOUT=40mA 2.156 2.200 2.244 V Input Voltage VIN 8 V Load Regulation ΔVOUT VIN=3.2V, 1mA≤IOUT≤200mA 40 100 mV Dropout Voltage VD1 IOUT=100mA 200 300 mV VD2 IOUT=200mA 400 600 Maximum Output Current IOUT(MAX) VIN=3.2V, VOUT≥VOUT× 0.90 400 mA Supply Current ISS VIN=3.2V, VEN=VIN 30.0 50.0 μA EN Input Bias Current IEH VEN=VIN 0.1 μA IEL VEN=0, VIN=3.2V to 8V 1.0 3.0 μA EN Input Threshold VEH VIN=3.2V to 8V VIN/2+0.8 VIN V VEL VIN=3.2V to 8V 0 0.4 V Line Regulation V △ OUT V △ IN×VOUT IOUT=40mA, 3.2V≤VIN≤8.0V 0.2 0.5 %/V Output Voltage Temperature Characteristics V △ OUT T △ OPR×VOUT IOUT=40mA ±100 ppm/°С |
|
|
