LR1122DG-XX-AF5-R Datasheet(PDF) 2 Page - Unisonic Technologies

Part # LR1122DG-XX-AF5-R
Description  LOW NOISE 200mA LDO REGULATOR
PDF  9 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Manufacturer  UTC [Unisonic Technologies]
Direct Link  http://www.utc-ic.com
Logo UTC - Unisonic Technologies

LR1122DG-XX-AF5-R Datasheet(HTML) 2 Page - Unisonic Technologies

  LR1122DG-XX-AF5-R Datasheet HTML 1Page - Unisonic Technologies LR1122DG-XX-AF5-R Datasheet HTML 2Page - Unisonic Technologies LR1122DG-XX-AF5-R Datasheet HTML 3Page - Unisonic Technologies LR1122DG-XX-AF5-R Datasheet HTML 4Page - Unisonic Technologies LR1122DG-XX-AF5-R Datasheet HTML 5Page - Unisonic Technologies LR1122DG-XX-AF5-R Datasheet HTML 6Page - Unisonic Technologies LR1122DG-XX-AF5-R Datasheet HTML 7Page - Unisonic Technologies LR1122DG-XX-AF5-R Datasheet HTML 8Page - Unisonic Technologies LR1122DG-XX-AF5-R Datasheet HTML 9Page - Unisonic Technologies
Zoom Inzoom in Zoom Outzoom out
 2 / 9 page
background image
LR1122D
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
2 of 9
www.unisonic.com.tw
QW-R502-320.E
MARKING
PACKAGE
VOLTAGE CODE
MARKING
SOT-25
12:1.2V
15:1.5V
16:1.6V
18:1.8V
20:2.0V
25:2.5V
2J:2.85V
30:3.0V
33:3.3V
3
2
1
5
4
SBXX
Voltage Code
L: Lead Free
G: Halogen Free
PIN CONFIGURATION
PIN DESCRIPTIONS
PIN NO.
PIN NAME
DESCRIPTION
1
VDD
Input Pin
2
GND
Ground Pin
3
CE
Chip Enable Pin. Active when this Pin is high.
4
NC
No Connection
5
VOUT
Output Pin
