MMBTA05

Preliminary

AMPLIFIER TRANSISTOR

UNISONICTECHNOLOGIESCO.,LTD

3 of 3

www.unisonic.com.tw

QW-R206-099.a

SWITCHING TIME TEST CIRCUIT

Figure 1. (Note: Total shunt capacitance of test jig and connectors for PNP test circuits, reverse all voltage polarities.)

TURN-ON TIME

5.0µs

+10V

0

5.0µF

100

100

-1.0V

+40V

OUTPUT

S

6.0pF

TURN-OFF TIME

5.0µs

5.0µF

100

100

+40V

OUTPUT

S

6.0pF
