1 / 3 page  UNISONIC TECHNOLOGIES CO., LTD SSM3K333R Preliminary Power MOSFET www.unisonic.com.tw 1 of 3 Copyright © 2012 Unisonic Technologies Co., Ltd QW-R502-736.a 6A, 30V N-CHANNEL POWER MOSFET DESCRIPTION The UTC SSM3K333R is an N-channel power MOSFET using UTC’s advanced technology to provide customers with a minimum on-state resistance and superior switching performance. The UTC SSM3K333R is usually used in power management switching applications. FEATURES * RDS(ON)<42mΩ @ VGS=4.5V RDS(ON)<28mΩ @ VGS=10V * High switching speed * Low gate charge (Typ.=3.4nC) * Low CRSS (Typ.=28pF) SYMBOL 2.Gate 1.Source 3. Drain ORDERING INFORMATION Ordering Number Package Pin Assignment Packing Lead Free Halogen Free 1 2 3 SSM3K333RL-AE3-R SSM3K333RG-AE3-R SOT-23 S G D Tape Reel Note: Pin Assignment: G: Gate D: Drain S: Source MARKING |
