background image
U74LVC1G07
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
4 of 5
www.unisonic.com.tw
QW-R502-215.E
DYNAMIC CHARACTERISTICS (TA=25°С)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Propagation delay from input
(A) to output(Y)
tPLZ/tPZL
VCC=1.8V±0.15V, CL=30pF, RL=1KΩ
2.4
8.3
ns
VCC=2.5V±0.2V,CL=30pF, RL=500Ω
1
5.5
ns
VCC=3.3V±0.3V,CL= 50 pF, RL=500Ω
1.5
4.2
ns
VCC= 5V±0.5V, CL= 50 pF, RL=500Ω
1
3.5
ns
OPERATING CHARACTERISTICS (TA=25°С)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Power Dissipation
Capacitance
CPD
VCC=1.8V, f=10MHz
3
3
pF
VCC=2.5V, f=10MHz
3
3
pF
VCC=3.3V , f=10MHz
3
4
pF
VCC=5V, f=10MHz
3
6
pF
