1 / 6 page  UNISONIC TECHNOLOGIES CO., LTD U74LVC1G32 CMOS IC www.unisonic.com.tw 1 of 6 Copyright © 2011 Unisonic Technologies Co., Ltd QW-R502-405.C SINGLE 2-INPUT POSITIVE-OR GATE DESCRIPTION The U74LVC1G32 is a single 2-input OR gate which provides the Function Y=A+B in positive logic circuit. This device has power-down protective circuit to prevent the device from destruction when it is powered down. FEATURES * Operate From 1.65V to 5.5V * Inputs Accept Voltages to 5.5V * IOFF Supports Partial-Power-Down Mode * Low Power Dissipation * Max tPD of 3.6 ns at 3.3V ORDERING INFORMATION Ordering Number Package Packing Lead Free Halogen Free U74LVC1G32L-AE5-R U74LVC1G32G-AE5-R SOT-23-5 Tape Reel U74LVC1G32L-AF5-R U74LVC1G32G-AF5-R SOT-25 Tape Reel U74LVC1G32L-AL5-R U74LVC1G32G-AL5-R SOT-353 Tape Reel MARKING 3C2 3 2 1 4 5 G: Halogen Free L:Lead Free |
