 4 / 5 page
background image
U74LVC2G34
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
4 of 5
www.unisonic.com.tw
QW-R502-430.A
SWITCHING CHARACTERISTICS (TA=25°С)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
VCC=1.65V~1.95V, RL=1KΩ
1.0
3.8
8.6
ns
VCC=2.3V~2.7V, RL=500Ω
CL=30pF
0.5
2.4
4.4
ns
VCC=2.7V, RL=500Ω
0.5
2.5
5.0
ns
VCC=3.0V~3.6V, RL=500Ω
0.5
2.2
4.1
ns
Propagation delay from input
(nA) to output(nY)
tPLH / tPHL
VCC=4.5V~5.5V, RL=500Ω
CL=50pF
0.5
1.9
3.2
ns
OPERATING CHARACTERISTICS (TA=25°С)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Power Dissipation Capacitance
CPD
VCC=3.3V, VIN=GND to VCC
20
pF
