DUAL SURFACE MOUNT

SWITCHING DIODE

DESCRIPTION

The UTC BAV70 is a dual surface mount switching diode providing

the designers high switching speed, high conductance and high

reliability.

The UTC BAV70 is suitable for common switching applications.

FEATURES

* High Switching Speed

* High Conductance

* High Reliability

* Green Product

SOT-23

(JEDEC TO-236)

1

2

3

ORDERING INFORMATION

Ordering Number

Package

Pin Assignment

Packing

Lead Free

Halogen Free

1

2

3

BAV70L-AE3-R

BAV70G-AE3-R

SOT-23

A1

A2

K1K2

Tape Reel

Note: Pin Assignment: A: Anode K: Cathode

MARKING

PIN CONFIGURATION
