BZT52

Preliminary

DIODE

www.unisonic.com.tw

1 of 2

Copyright © 2012 Unisonic Technologies Co., Ltd

QW-R601-065.a

SURFACE MOUNT SILICON

ZENER DIODE

DESCRIPTION

The UTC BZT52 is a surface mount silicon Zener Diode using

UTC’s advanced technology to provide customers with low power

dissipation.

The UTC BZT52 is universally applied in Automated Assembly

Processes.

FEATURES

* Low Power Dissipation: 200mW

* Zener Voltage (Typically 5.6V)

* Planar Die construction

ORDERING INFORMATION

Ordering Number

Package

Pin Assignment

Packing

Lead Free

Halogen Free

1

2

BZT52L-CB2-R

BZT52G-CB2-R

SOD-323

A

K

Tape Reel

Note: Pin Assignment: A: Anode, K: Cathode

MARKING

PACKAGE

MARKING

SOD-323

T56

L: Lead Free

G: Halogen Free
