2 / 4 page ![]() UT2309 Power MOSFET UNISONICTECHNOLOGIESCO.,LTD 2 of 4 www.unisonic.com.tw QW-R502-148.E ABSOLUTE MAXIMUM RATINGS PARAMETER SYMBOL RATINGS UNIT Drain-Source Voltage VDSS -30 V Gate-Source Voltage VGSS ±20 V Continuous Drain Current (Note 3) ID -3.7 A Pulsed Drain Current (Note 1, 2) IDM -12 A Total Power Dissipation PD 1.38 W Junction Temperature TJ +150 °C Storage Temperature TSTG -55 ~ +150 °C Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied. THERMAL DATA PARAMETER SYMBOL RATINGS UNIT Junction to Ambient (Note 3) θJA 90 °C/W ELECTRICAL CHARACTERISTICS (TJ =25°C, unless otherwise specified) PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT OFF CHARACTERISTICS Drain-Source Breakdown Voltage BVDSS VGS =0 V, ID =-250 µA -30 V Drain-Source Leakage Current IDSS VDS=-30V, VGS=0V -0.5 uA Gate-Source Leakage Current IGSS VGS= ±20V, VDS=0V 5 nA Breakdown Voltage Temperature Coefficient ΔBVDSS/ΔTJ Reference to 25°C, ID=-1mA -0.02 V/°C ON CHARACTERISTICS Gate Threshold Voltage VGS(TH) VDS=VGS, ID=-250uA -1 -3 V Static Drain-Source On-Resistance (Note 2) RDS(ON) VGS=-10V, ID=-3A 75 mΩ VGS=-4.5V, ID=-2.6A 120 mΩ DYNAMIC CHARACTERISTICS Input Capacitance CISS VGS=0V,VDS=-25V,f=1.0MHz 412 660 pF Output Capacitance COSS 91 pF Reverse Transfer Capacitance CRSS 62 pF SWITCHING CHARACTERISTICS Turn-ON Delay Time (Note 2) tD(ON) VDS=-15V,ID=-1A,RG=3.3Ω, VGS=-10V,RD=15Ω 8 ns Turn-ON Rise Time tR 5 ns Turn-OFF Delay Time tD(OFF) 20 ns Turn-OFF Fall Time tF 7 ns Total Gate Charge (Note 2) QG VDS=-24V, VGS=-4.5V, ID=-3A 5 8 nC Gate-Source Charge QGS 1 nC Gate-Drain Charge QGD 3 nC SOURCE- DRAIN DIODE RATINGS AND CHARACTERISTICS Forward On Voltage VSD IS=-1A, VGS=0V -0.76 -1.2 V Reverse Recovery Time tRR IS=-3A, VGS=0V, dI/dt=-100A/μs 20 ns Reverse Recovery Charge QRR 15 nC Notes: 1. Pulse width limited by TJ(MAX) 2. Pulse width ≤300us , duty cycle ≤2%. 3. Surface mounted on 1 in 2 copper pad of FR4 board. |
|
|
