1 / 5 page  UNISONIC TECHNOLOGIES CO., LTD UTD405 Power MOSFET www.unisonic.com.tw 1 of 5 Copyright © 2008 Unisonic Technologies Co., Ltd QW-R502-199.A P-CHANNEL ENHANCEMENT MODE DESCRIPTION The UTD405 can provide excellent RDS(ON), low gate charge and low gate resistance by using advanced trench technology. This device is well suited for high current load applications with the excellent thermal resistance. FEATURES * RDS(ON) = 32mΩ @VGS = -10 V * Low capacitance * Low gate charge * Fast switching capability * Avalanche energy specified SYMBOL 1.Gate 3.Source 2.Drain *Pb-free plating product number: UTD405L ORDERING INFORMATION Ordering Number Pin Assignment Normal Lead Free Plating Package 1 2 3 Packing UTD405-TN3-R UTD405L-TN3-R TO-252 G D S Tape Reel UTD405-TN3-T UTD405L-TN3-T TO-252 G D S Tube |
