WI.DP1203-XXX-R DATASHEET
14
8. Mechanical Dimensions
The following diagram shows the physical footprint and dimensions of the Wi.DP1203-XXX-R
TM drop-in module,
which should be implemented on the mother board.
Figure 6: Mechanical Dimensions
