TNC
Amphenol
®
Angle Plugs
Cable
Conn.
Cable Attachment
Dimensions, inches (millimeters)
Notes
Military
Amphenol
Fig.
RG-/U
Type
Outer
Inner
a
b
c G
d
CAI
Plt.
Ins.
Number
Number
55, 58, 141
142, 223, 400
Angle Plug
Clamp
Solder
1.12(28.6)
.610(15.5)
.224(5.7)
1.58(40.1)
C34
P1
D1
—
79075 *
1
55, 142, 223, 400 Angle Plug
Crimp
Crimp
1.19(30.2)
.562(14.3)
.220(5.6)
1.58(40.1)I
C36
P17
D1
—
31-2381
2
58, 141
Angle Plug
Crimp
Crimp
1.19(30.2)
.562(14.3)
.206(5.2)
1.58(40.1)
C36
P17
D1
—
31-2382
2
62
Angle Plug
Crimp
Crimp
1.19(30.2)
.562(14.3)
.261(6.6)
1.58(40.1)
C36
P17
D1
—
31-2383
2
TNC ANGLE PLUGS & JACKS
Fig. 1
Fig. 2
TNC Clamp Type Angle Plug
79075
TNC Crimp Type Angle Plug
31-2381
31-2382
31-2383
L
a
b
c•
d
c•
a
d
b
* recognized under the component program of U.L., Inc.
• accommodates cable diameter
I includes outer ferrule L distributor stocked


Similar Part No. - 031-2389-RFX
