DATA SHEET

SE5023L: 5 GHz, 26dBm Power Amplifier with Power Detector

Preliminary Information

Skyworks Solutions, Inc. ● Phone [781] 376-3000 ● Fax [781] 376-3100 ● sales@skyworksinc.com ● www.skyworksinc.com

DST-00497  Rev 1.1 ● Skyworks Proprietary Information ● Products and Product Information are Subject to Change Without Notice ● May 09, 2012

6 of 11

AC Electrical Characteristics

802.11a AC Electrical Characteristics

Conditions: VCC = 5.0 V, VREF = 2.85 V, f = 5.4 GHz, TA = 25 °C, as measured on Skyworks Solutions’ SE5023L-

EK1 evaluation board, unless otherwise noted

Symbol

Parameter

Conditions

Min.

Typ.

Max.

Unit

fL-U

Frequency Range

5.15

5.85

GHz

POUT

Output Power

802.11ac, 256 QAM, 1.8% EVM

dBm

802.11a, 64 QAM, 3% EVM

802.11n, MCS0, Mask Compliant

P1dB

Output 1dB

compression point

No modulation

dBm

S21

Small Signal Gain

PIN = -25 dBm

ΔS21

Gain Variation

Within each UNII Band

ΔS21 3.8

Gain at 3.8GHz

PIN = -25 dBm

Harmonic

POUT = 26 dBm, 5V

-45

dBm/MHz

tr, tf

Rise and Fall Time

0.15

0.3

STAB

Stability

POUT = 26 dBm, VCC = 5V, 54 Mbps,

64 QAM, VSWR = 6:1, all phases

All non-harmonically related outputs

less than -50 dBc/100 kHz

Rugged-

ness

Tolerance to

constant input power

into a mismatch load

PIN = -10dBm, CW,

VSWR = 6:1, all phases

No damage
