TECHNICAL DATA SHEET

N Male Connector Crimp/Solder Attachment For RG8X, PE-C240

N Male Connector Crimp/Solder Attachment For RG8X, PE-C240

Configuration

Connector

N Male

Connector Specification

MIL-STD-348A

Connector Interface Type

RG8X,PE-C240

Cable Attachment Method (Shield/Contact)

Crimp/Solder

Body Style

Straight

Electrical Specifications

Frequency Range, GHz

DC to 11

Impedance, Ohms

50

Maximum Operating Voltage, Volts

1,000

Dielectric Withstanding Voltage, Vrms

1,500

Mechanical Specifications

Temperature

Operating Range, deg C

-65 to +165

Size

Length, in [mm]

1.394 [35.41]

Width/Dia., in [mm]

0.827 [21]

Weight, lbs [g]

0.082 [37.19]

Connector

Type

N Male

Contact Material and Plating

Brass, Gold

Contact Plating Specification

30µ in. minimum

Body Material and Plating

Brass, Nickel

Body Plating Specification

100µ in. minimum

Dielectric Type

Teflon

RoHS Compliant

Yes

Plotted and Other Data

Notes:

Values at 25 °C, sea level

N Male Connector Crimp/Solder Attachment For RG8X, PE-C240 from Pasternack Enterprises has same day shipment for

domestic and International orders. We maintain 99% availability of the industry’s broadest selection of RF, microwave and

fiber optic products.

PE4344

PE4344 REV
