Copyright 2012. RMT Ltd. The design and specifications of products can be changed by RMT Ltd without notice.

Page 2 of 8

Performance

Data

2MC04-059-05AN

Performance

Data

2MC04-059-08AN

Thermoelectric Cooling Solutions

@ 27ºC, Vacuum

ΔTmax

K

Qmax

W

Imax

A

Umax

V

2MC04-059-05AN

103

1.70

1.2

5.9

@50ºC, N2

ΔTmax

K

Qmax

W

Imax

A

Umax

V

2MC04-059-05AN

108

1.87

1.2

6.6

Note: Performance data is specified for optimal optimal conditions (TEC hot side is stabilized at ambient temperature).

Heatsink thermal resistance is not included into estimations. Use TECCad Software for estimations under different conditions.

@ 27ºC, Vacuum

ΔTmax

K

Qmax

W

Imax

A

Umax

V

2MC04-059-08AN

104

1.07

0.8

5.9

@50ºC, N2

ΔTmax

K

Qmax

W

Imax

A

Umax

V

2MC04-059-08AN

107

1.18

0.8

6.6

Note: Performance data is specified at optimal optimal conditions (TEC hot side is stabilized at ambient temperature). Any

heatsink thermal resistance is not included into estimations. Use TECCad Software for estimations under different conditions.
