TECHNICAL DATA SHEET

7/16 DIN Female Bulkhead Connector Crimp/Solder Attachment For PE-C240, LMR-240, RG8X

Configuration

Connector

7/16 DIN Female

Connector Interface Type

PE-C240,LMR-240,RG8X

Cable Attachment Method (Shield/Contact)

Crimp/Solder

Body Style

Straight

Mount Method

Bulkhead

Electrical Specifications

Impedance, Ohms

50

Mechanical Specifications

Size

Length, in [mm]

2.03 [51.56]

Width/Dia., in [mm]

1.54 [39.12]

.

Weight, lbs [g]

0.11 [49.9]

Connector

Type

7/16 DIN Female

Contact Material and Plating

Silver

Body Material and Plating

Brass, Tri-Metal

Dielectric Type

PTFE

RoHS Compliant

Yes

Plotted and Other Data

Notes:

Values at 25 °C, sea level

7/16 DIN Female Bulkhead Connector Crimp/Solder Attachment For PE-C240, LMR-240, RG8X from Pasternack Enterprises

has same day shipment for domestic and International orders. Our RF, microwave and fiber optic products maintain a 99%

availability and are part of the broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: 7/16 DIN Female Bulkhead Connector Crimp/Solder Attachment For PE-C240, LMR-240, RG8X

PE44549

URL: http://www.pasternack.com/7-16-female-standard-pe-c240-0.240-connector-pe44549-p.aspx

PE44549

PE44549 REV 01

7/16 DIN Female Bulkhead Connector Crimp/Solder

Attachment For PE-C240, LMR-240, RG8X
