DB151S THRU DB157S

SINGLE PHASE GLASS PASSIVATED BRIDGE RECTIFIERS

Voltage Range - 50 to 1000 Volts

Current - 1.5 Ampere

Case: Molded plastic body

Terminals: Plated leads solderable per MIL-STD-750,

Method 2026

Polarity: Polarity symbols marked on case

Mounting Position: Any

Weight:0.02 ounce, 0.4 grams

FEATURES

MECHANICAL DATA

Dimensions in inches and (millimeters)

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

-55 to +150

-55 to +150

50

35

50

100

70

100

200

140

200

400

280

400

600

420

600

800

560

800

1000

700

1000

MDD

DB151S

1.5

NOTES:DBS for surface mount package.

Ideal for printed circuit board

Reliable low cost construction utilizing

molded plastic technique

High temperature soldering guaranteed:

250*/10 seconds / 0.375''(9.5mm)

led length at 5 lbs., (2.3kg)tension

Small size, simple installation

Leads solderable per MIL-STD-202,

Method 208

High surge current capability

Single phase half-wave 60Hz,resistive or inductive load, For capacitive load derate current by 20%.

VOLTS

VOLTS

VOLTS

SYMBOLS

UNITS

Amps

Amps

Volts

Maximum repetitive peak reverse voltage

Maximum RMS voltage

Maximum DC blocking voltage

Maximum average forward rectified current

Peak forward surge current

8.3ms single half sine-wave superimposed on

rated load (JEDEC Method)

Maximum instantaneous forward voltage drop

per birdge element at 1.5A

Maximum DC reverse current

at rated DC blocking voltage

Operating temperature range

storage temperature range

A

µ

1.1

MDD

DB152S

MDD

DB153S

MDD

DB154S

MDD

DB155S

MDD

DB156S

MDD

DB157S

50

10

500

+

.047(1.20)

.040(1.02)

.205(5.2)

.195(5.0)

.130(3.30)

.120(3.05)

.335(8.51)

.320(8.13) 45

.404(10.3)

.386(9.80)

.255(6.5)

.245(6.2)

.060(1.53)

.040(1.02)

.013(0.33)

.0088(0.22)

.013(0.33)

.003(0.076)

DBS

A

µ

MDD ELECTRONIC

MDD Catalog Number

C

C
