DB152S Datasheet(PDF) 15 Page - Kingtronics International Company |
|
|
|||||||||||||||||||||||||||||
DB152S Datasheet(HTML) 15 Page - Kingtronics International Company |
|
|
15 / 18 page  Website: www.kingtronics.com Email: info@kingtronics.com Tel: (852) 8106 7033 Fax: (852) 8106 7099 15 BRIDGE RECTIFIER Max.Reverse Voltage Max.Aver. Rect.Current Peak Fwd. Surge Current Max.Fwd. Voltage @25℃ & Rated Io Maximum Reverse Current@Rated VRM & Tc Typical Thermal Resist. Operation Temp. Range TYPE NO. VRM(V) Io(A) IFSM(A) Rated Io(A) VF(V) IR@25℃ IR(uA) IR@100℃ IR(uA) RθJA/RθJL(℃/W) Tj(℃) Package GBPC2502 200 25.0 400 12.5 1.1 5.0 500 1.5 -55~+150 GBPC GBPC2504 400 25.0 400 12.5 1.1 5.0 500 1.5 -55~+150 GBPC GBPC2506 600 25.0 400 12.5 1.1 5.0 500 1.5 -55~+150 GBPC GBPC2508 800 25.0 400 12.5 1.1 5.0 500 1.5 -55~+150 GBPC GBPC2510 1000 25.0 400 12.5 1.1 5.0 500 1.5 -55~+150 GBPC S25VB10 100 25.0 400 12.5 1.1 10.0 500 1.2 -55~+150 S25VB S25VB20 200 25.0 400 12.5 1.1 10.0 500 1.2 -55~+150 S25VB S25VB40 400 25.0 400 12.5 1.1 10.0 500 1.2 -55~+150 S25VB S25VB60 600 25.0 400 12.5 1.1 10.0 500 1.2 -55~+150 S25VB S25VB80 800 25.0 400 12.5 1.1 10.0 500 1.2 -55~+150 S25VB S25VB100 1000 25.0 400 12.5 1.1 10.0 500 1.2 -55~+150 S25VB GBPC35005 50 35.0 400 17.5 1.1 5.0 500 1.5 -55~+150 GBPC GBPC3501 100 35.0 400 17.5 1.1 5.0 500 1.5 -55~+150 GBPC GBPC3502 200 35.0 400 17.5 1.1 5.0 500 1.5 -55~+150 GBPC GBPC3504 400 35.0 400 17.5 1.1 5.0 500 1.5 -55~+150 GBPC GBPC3506 600 35.0 400 17.5 1.1 5.0 500 1.5 -55~+150 GBPC GBPC3508 800 35.0 400 17.5 1.1 5.0 500 1.5 -55~+150 GBPC GBPC3510 1000 35.0 400 17.5 1.1 5.0 500 1.5 -55~+150 GBPC GBPC50005 50 50.0 500 25 1.1 5.0 500 1.5 -55~+150 GBPC GBPC5001 100 50.0 500 25 1.1 5.0 500 1.5 -55~+150 GBPC GBPC5002 200 50.0 500 25 1.1 5.0 500 1.5 -55~+150 GBPC GBPC5004 400 50.0 500 25 1.1 5.0 500 1.5 -55~+150 GBPC GBPC5006 600 50.0 500 25 1.1 5.0 500 1.5 -55~+150 GBPC GBPC5008 800 50.0 500 25 1.1 5.0 500 1.5 -55~+150 GBPC GBPC5010 1000 50.0 500 25 1.1 5.0 500 1.5 -55~+150 GBPC GBPC15005W 50 15.0 300 7.5 1.1 5.0 500 1.5 -55~+150 GBPC-W GBPC1501W 100 15.0 300 7.5 1.1 5.0 500 1.5 -55~+150 GBPC-W GBPC1502W 200 15.0 300 7.5 1.1 5.0 500 1.5 -55~+150 GBPC-W GBPC1504W 400 15.0 300 7.5 1.1 5.0 500 1.5 -55~+150 GBPC-W GBPC1506W 600 15.0 300 7.5 1.1 5.0 500 1.5 -55~+150 GBPC-W GBPC1508W 800 15.0 300 7.5 1.1 5.0 500 1.5 -55~+150 GBPC-W GBPC1510W 1000 15.0 300 7.5 1.1 5.0 500 1.5 -55~+150 GBPC-W Note: Specifications are subject to change without notice. |
|
|
