TECHNICAL DATA SHEET

SMA Male Precision Connector Solder Attachment For PE-SR402AL, PE-SR402FL, PE-SR402FLJ, RG402

Configuration

Connector

SMA Male

Connector Interface Type

PE-SR402AL,PE-SR402FL,PE-SR402FLJ,RG402

Cable Attachment Method (Shield/Contact)

Solder

Connector Design

Precision

Body Style

Straight

Electrical Specifications

Frequency Range, GHz

DC to 18

Impedance, Ohms

50

Mechanical Specifications

Size

Length, in [mm]

0.441 [11.2]

Width/Dia., in [mm]

0.315 [8.00]

.

Connector

Type

SMA Male

Coupling Nut Material and Plating

Passivated Stainless Steel

Hex Size, in.

5/16

Torque, in-lbs [Nm]

8 [0.9]

Body Material and Plating

Brass, Gold

RoHS Compliant

Yes

Plotted and Other Data

Notes:

Values at 25 °C, sea level
