Mechanical Dimension :

Features

DELTA ELECTRONICS, INC.

TEL: 886-3-3591968; FAX: 886-3-3591991

http://www.deltaww.com

SMT Power Inductor

HMP1350 Type

N

M

L

K

O

C

J

E

D

H

A

UNIT : mm/inch

D = 7.80 / 0.307

F = 2.50 / 0.098

G = 2.50 / 0.098

H = 8.00 / 0.315

J = 3.20 / 0.126

K = 7.00 / 0.276

L = 14.00 / 0.551

M = 3.70 / 0.146

121

G

F

1

UNIT : mm/inch

PART NO.

C (MAX)

E

N

O

B

A

1. Tolerance of inductance is

20%.

2. Isat is the DC current which cause the inductance drop to Li.

O

OO

rms

L

(uH)

Li

(uH) MIN

I

(Adc)

(m

) MAX

DCR

sat

I

(Adc)

1

3

2

HMP1350

12.70

0.5 / 0.50

0.02

13.00

0.5 / 0.512

0.02

5.00 / 0.197

2.40 / 0.094

11.20 / 0.441

4.40 / 0.173

HMP1350S

12.70

0.5 / 0.50

0.02

13.00

0.5 / 0.512

0.02

5.00 / 0.197

2.00 / 0.079

10.80 / 0.425

4.80 / 0.189

RECOMMENDED PAD PATTERNS

RoHS compliant.

Low profile, SMD type.

High current.

Magnetic shielded.

High energy storage and low DCR.

Provided with embossed carrier tape packing.

Ideal for power source circuits, DC-DC converter, DC-AC inverters

inductor applications.

In addition to the standard versions shown here, customized inductors

are available to meet your exact requirements.

HMP1350M-0R5

0.5

0.40

1.3

40.0

30.0

HMP1350-0R6

0.6

0.48

1.3

30.0

30.0

HMP1350-0R7

0.7

0.56

1.3

30.0

30.0

HMP1350-1R0

1.0

0.80

2.1

30.0

26.0

HMP1350-1R5

1.5

1.20

2.1

20.0

26.0

HMP1350-2R0

2.0

1.60

3.5

20.0

17.0

HMP1350M-2R2

2.2

1.76

4.3

18.0

15.8

HMP1350-3R3LD

3.3

2.30

4.3

14.0

15.8

HMP1350BM-4R7

4.7

3.76

6.3

13.5

12.5

HMP1350-150

15.0

12.00

26.0

5.4

7.5

HMP1350S-R85

0.85

0.68

1.3

20.0

30.0
