1 / 2 page  http://www.adlinktech.com/AdvancedTCA/ 1 1-9 aTCA-6250 Specifications CPU / Chipset / Memory CPU Two Intel® Xeon® E5-2658 (8C/16T) (Socket R) Two Intel® Xeon® E5-2648L (8C/16T) (Socket R) Chipset Intel® C604 PCH Memory Eight DDR3-1600 240-pin VLP RDIMM sockets, up to 128 GB BIOS Chip AMI BIOS on SPI flash memory Features Intel® PXE pre-boot Remote Console I/O Interfaces Graphics Silicon Motion SM750, PCI-E x1, up to 1920 x 1440 resolution Ethernet Dual 10/100/1000BASE-T Base Interface channels Dual 10GBASE-KX4 Fabric Interface channels Quad 10/1001000BASE-T Egress Ports or Quad SFP GbE Egress ports (optional) Storage On-board bootable 16GB SATA DOM, up to 32G USB Two USB 2.0 ports on front panel Front Panel I/O VGA, USB1/2, LAN1/2/3/4, COM1/2 (mini-USB) PICMG Standards AdvancedTCA PICMG 3.0 R3.0 PICMG 3.1 Ethernet Over PICMG 3.0, Option 9 Other Features Packet Processing Optional hardware offload for packet processing acceleration Acceleration daughter card Operating System Server 2008 R2, Red Hat Enterprise Linux 6.2 Mechanical and Environmental Form Factor PICMG 3.0 R3.0 AdvancedTCA Dimension 322.25mm x 280mm x 6HP (L x W x H) Weight 3.85KG Operating Temp. 0°C to 55°C Storage Temp. -40°C to 70°C Humidity 5% to 95%, non-condensing Shock 20G peak-to-peak, 11ms duration, non-operating Vibration Non-operating: 1.88Grms, 5-500Hz each axis Operating: 0.5Grms, 5-500Hz each axis Power Consumption Max. 300W with dual Intel® E5-2658 CPU/250W with dual Intel® E5-2648L CPU Certification FCC, CE, UL, NEBS Level 3 (design) Dual Intel® Xeon® E5-2658/2648L 10 Gigabit Ethernet AdvancedTCA® Processor Blade Features Two Intel® Xeon® E5-2658/ 2648L (8C/16T) processors Eight memory sockets support VLP DDR3-1600 REG/ECC up to 128 GB Intel® C604 PCH Dual 10GBASE-KX4 Fabric Interface channels Intel® Hyper-Threading Technology Intel® QuickPath Interconnect Ordering Information Model Number Description/Configuration aTCA-6250/S2658 Single 8-core Intel® Xeon® E5-2658 2.1GHz 10GbE processor blade aTCA-6250/S2658/M8G Single 8-core Intel® Xeon® E5-2658 2.1GHz 10GbE processor blade, DDR3-1600 VLP RDIMM 8GB x1 aTCA-6250/D2658 Dual 8-core Intel® Xeon® E5-2658 2.1GHz 10GbE processor blade aTCA-6250/D2658/M32G Dual 8-core Intel® Xeon® E5-2658 2.1GHz 10GbE processor blade, DDR3-1600 VLP RDIMM 8GB x4 aTCA-R6270 aTCA-R6270 RTM with 1x RJ45 Serial Port, 2x USB 2.0 Port, 2x SFP+ 10GbE Port and 2x SAS/SATA HDD Bay (Hot Swappable) |
