ATCA-R6905 Datasheet(PDF) 1 Page - List of Unclassifed Manufacturers |
|
|
|||||||||||||||||||||||||||||
ATCA-R6905 Datasheet(HTML) 1 Page - List of Unclassifed Manufacturers |
|
|
1 / 2 page  http://www.adlinktech.com/AdvancedTCA/ Specifications CPU / Chipset / Memory CPU Two Quad-Core Intel® Xeon® L5408 2.13 GHz, FSB 1066 MHz, 12 MB L2 Cache (FC-LGA6) Two Dual-Core Intel® Xeon® 5138 2.13 GHz, FSB 1066 MHz, 4MB L2 Cache (FC-LGA6) Chipset Intel® 5100/ICH9R Chipset Memory Four DDR2-667 240-pin RDIMM sockets, up to 32 GB BIOS Chip AMIBIOS®8 on SPI flash memory Features Intel® PXE pre-boot Remote Console I/O Interfaces Graphics ATI ES1000 with 64 MB VRAM, up to UXGA 1600 x 1200 resolution AdvancedMC AMC1: AMC.0 Mid-size, AMC.1 Type4, AMC.2 E2/Type3, AMC.3 S2 AMC2: AMC.0 Mid-size, AMC.1 Type1, AMC.2 E2/Type3, AMC.3 S2 Ethernet Dual 10/100/1000BASE-T Base Interface channels Dual 10GBASE-KX4/1000BASE-BX Fabric Interface channels Dual 10/1001000BASE-T Egress ports Optional on-board 24-port Gigabit Ethernet Switch-on-Chip Storage Dual AMC.3 SATA 3 Gb/s ports (Port2) Dual AMC.3 SAS ports (Port3) On-board bootable 4 GB USB flash memory USB Three USB 2.0 ports Front Panel I/O AMC1/2, VGA, USB1/2/3, LAN1/2, COM1 PICMG Standard AdvancedTCA PICMG® 3.0 R2.0 ECN001 PICMG® 3.1 Ethernet Over PICMG 3.0 R1.0 , Option1/9 AdvancedMC PICMG® AMC.0: Advanced Mezzanine Card Specification R2.0 PICMG® AMC.1: PCI Express and Advanced Switching R1.0 PICMG® AMC.2: Gigabit Ethernet R1.0 PICMG® AMC.3: Storage Interfaces R1.0 Other Features Operating System Windows® XP Professional, Windows® Server 2003, Fedora™ 8 and 9, Red Hat Enterprise Linux® 5.2 Mechanical and Environmental Form Factor PICMG® 3.0 R2.0 ECN001 AdvancedTCA® Dimensions 322.25mm x 280mm x 6HP (L x W x H) Weight 2.8 kg / 6 lbs Operating Temp. 0˚C to 50˚C Storage Temp. -20˚C to 80˚C Humidity 5% to 95%, non-condensing Shock 15G peak-to-peak, 11ms duration, non-operation Vibration Non-operation: 1.88Grms, 5-500Hz each axis Operation: 0.5Grms, 5-500Hz each axis Power Consumption 168W (Dual Quad-Core Intel® Xeon® L5408 with 100% CPU Usage) Certifications FCC, CE, CUL, NEBS Level 3 (design) Dual Quad-Core LV Xeon® 10 Gigabit Ethernet AdvancedTCA® Processor Blade aTCA-6900 Features Two Quad-Core or Dual-Core Intel® LV Xeon® processors Intel® EM64T 64-bit Extended Memory Technology DDR2-667 REG/ECC memory up to 32 GB maximum capacity Intel® 5100/ICH9R chipset Dual AMC.0 Mid-size bays Dual 10GBASE-KX4/1000BASE-BX Fabric interface channels RAID 0/1/10 SATA/SAS ports Optional on-board 24-port Gigabit Ethernet Switch-on-Chip Ordering Information Model Number Description/Configuration aTCA-6900/D5138 Two LV-5138 Dual-Core 2.13GHz Xeon® 10GbE processor blade aTCA-6900/D5408 Two L5408 Quad-Core 2.13GHz Xeon® 10GbE processor blade aTCA-6900S/D5138 Two LV-5138 Dual-Core 2.13GHz Xeon® 10GbE processor blade w/ switch aTCA-6900S/D5408 Two L5408 Quad-Core 2.13GHz Xeon® 10GbE processor blade w/ switch AMC-7000/SATA250G Mid-size SATA 1.5 Gb/s 250GB AMC HDD module aTCA-R6905 Rear Transition Module with SFP GbE x2, USB x2, SAS/SATA HDD bay x2, COM x1 |
