ABSOLUTE MAXIMUM RATINGS

PARAMETER

SYMBOL

RATINGS

UNIT

Repetitive Peak Reverse Voltage

VRRM

200

Continuous Reverse Voltage

150

Forward DC Current at TA=25°C (Note 1)

250

Rectified Current (Average) Half Wave Rectification with

Resist. Load at TA=25°C (Note 1)

200

Repetitive Peak Forward Current at f>50Hz, TA=25°C

(Note 1)

IFRM

625

Surge Forward Current at t<1s, TJ=25°C

IFSM

1.0

Power Dissipation at TA=25°C (Note 1)

410

Junction Temperature

-55~+150

°C

Storage Temperature

TSTG

-55~+150

°C

Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. Valid provided that leads are kept at ambient temperature



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

θJA

200

°C/W



ELECTRICAL CHARACTERISTICS (TA=25°C, unless otherwise specified)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP MAX UNIT

Forward Voltage

IF=100mA

1.00

IF=200mA

1.25

Leakage Current

VR=150V

100

VR=150V, TJ=100°C

μA

Dynamic Forward Resistance

IF=10mA

5.0

Ω

Reverse Recovery Time

trr

IF=30mA, IR=30mA, Irr=3.0mA,

RL=100Ω

Capacitance Between Terminals

VR=0 , f=1.0MHz

1.5
