background image
NICHIA STS-DA1-2673B <Cat.No.130531>
1
SPECIFICATIONS
(1) Absolute Maximum Ratings
Item
Symbol
Absolute Maximum Rating
Unit
Forward Current
IF
300
mA
Pulse Forward Current
IFP
450
mA
Allowable Reverse Current
IR
85
mA
Power Dissipation
PD
12
W
Operating Temperature
Topr
-40~100
°C
Storage Temperature
Tstg
-40~100
°C
Junction Temperature
TJ
130
°C
* Absolute Maximum Ratings at TC=25°C.
* IFP conditions with pulse width ≤10ms and duty cycle ≤10%.
* The operating Temperature (Topr) range is the range of case temperatures.
(2) Initial Electrical/Optical Characteristics
Item
Symbol
Condition
Typ
Max
Unit
Forward Voltage
VF
IF=160mA
36.3
-
V
Luminous Flux
Φv
IF=160mA
805
-
lm
Color Rendering Index
Ra
IF=160mA
73
-
-
x
-
IF=160mA
0.3818
-
-
R70
Chromaticity Coordinate
y
-
IF=160mA
0.3797
-
-
Luminous Flux
Φv
IF=160mA
690
-
lm
Color Rendering Index
Ra
IF=160mA
83
-
-
x
-
IF=160mA
0.4338
-
-
R8000
Chromaticity Coordinate
y
-
IF=160mA
0.4030
-
-
Thermal Resistance
RθJC
-
3.5
3.9
°C/W
* Characteristics at TC=25°C.
* Luminous Flux value as per CIE 127:2007 standard.
* Chromaticity Coordinates as per CIE 1931 Chromaticity Chart.
* RθJC is Thermal Resistance from junction to TC measuring point.
