Compact Flash 5 series

AP-CFxxxxRXXS-XXXXXXA

1

© 2013 Apacer Technology Inc.

Rev. 1.2

Features:

CompactFlash Association Specification

Revision 4.1 Standard Interface

–

512 bytes per sector

–

ATA command set compatible

–

ATA transfer mode supports:

PIO Mode 6

Multiword DMA Mode 4

Ultra DMA Mode 5

PCMCIA UDMA Mode 5

Capacities

–

128, 256, 512 MB

1, 2, 4, 8, 16, 32, 64 GB

Performance

–

Sustained read: Up to 55 MB/sec

–

Sustained write: Up to 42 MB/sec

Intelligent ATA/IDE module

–

Wear-leveling algorithms to substantially

increase longevity of flash media

–

Built-in BCH ECC capable of correcting

up to 24 bits in 1,024 byte data

–

Flash block management

–

Power failure management

–

Supports S.M.A.R.T commands

NAND Flash Type: SLC

Temperature ranges

–

0°C to 70°C for operation (Standard)

–

-40°C to 85°C for operation (Extended)

–

-40°C to 100°C for storage

Operating voltage

–

3.3 V

–

5.0 V

Power consumption (typical)**

–

Active mode: 175 mA

–

Standby mode: 3 mA

Connector Type

–

50 pins female

Physical Dimensions

–

36.4mm x 42.8mm x 3.3mm

Endurance (TBW: Terabytes Written)

–

128 MB: 0.5 TBW

–

256 MB: 1.1 TBW

–

512 MB: 2.3 TBW

–

1 GB: 4.5 TBW

–

2 GB: 9.1 TBW

–

4 GB: 18.2 TBW

–

8 GB: 36.5 TBW

–

16 GB: 73.0 TBW

–

32 GB: 146.0 TBW

–

64 GB: 292.1 TBW

Halogen free

*Performance and power consumption may vary depending on host system configurations.
