Compact Flash 5 series

AP-CFxxxxRXXS-XXXXXXA

8

© 2013 Apacer Technology Inc.

Rev. 1.2

4.3 Environmental Specifications

Environmental specification of the Compact Flash Card series (CFC) which follows the MIL-STD-810F

standards is available as shown in Table 4-3.

Table 4-3: Environmental specifications

Environment

Specification

Operation

0°C to 70°C; -40°C to 85°C (Extended Temperature)

Temperature

Storage

-40°C to 100°C

Vibration (Non-Operation)

Sine wave : 10~2000Hz, 15G (X, Y, Z axes)

Shock (Non-Operation)

Half sine wave 1,500G (X, Y, Z ; All 6 axes)

4.4 Certification & Compliance

The CompactFlash card complies with the following global standards:

CE

FCC

Halogen-free

CompactFlash Association Specification Revision 4.1

EMC

4.5 Endurance

The endurance of a storage device is predicted by TeraBytes Written based on several factors related to

usage, such as the amount of data written into the drive, block management conditions, and daily

workload for the drive. Thus, key factors, such as Write Amplifications and the number of P/E cycles, can

influence the lifespan of the drive.

Capacity

TeraBytes Written

128 MB

0.5

256 MB

1.1

512 MB

2.3

1 GB

4.5

2 GB

9.1

4 GB

18.2

8 GB

36.5

16 GB

73.0

32 GB

146.0

64 GB

292.1

Notes:

The measurement assumes the data written to the SSD for test is under a typical and constant rate.

The measurement follows the standard metric: 1 TB (Terabyte) = 1000 GB.
