TF708 Datasheet(PDF) 1 Page - Dynex Semiconductor |
|
|
|||||||||||||||||||||||||||||
TF708 Datasheet(HTML) 1 Page - Dynex Semiconductor |
|
|
1 / 13 page  TF708..B 1/13 APPLICATIONS s High Power Inverters And Choppers s UPS s Railway Traction s Induction Heating s AC Motor Drives s Cycloconverters FEATURES s Double Side Cooling s High Surge Capability s High Voltage VOLTAGE RATINGS KEY PARAMETERS V DRM 2000V I T(RMS) 750A I TSM 8000A dV/dt 300V/ µs dI/dt 500A/ µs t q 40 µs Conditions V RSM = VRRM + 100V I DRM = IRRM = 60mA at V RRM or VDRM & Tvj Repetitive Peak Voltages V DRM VRRM Type Number 2000 1800 1600 Lower voltage grades available. TF708 20B TF708 18B TF708 16B Outline type code: MU171. See Package Details for further information. CURRENT RATINGS Parameter Conditions Max. Units Mean on-state current RMS value Half sinewave, 50Hz, T case = 80 oC Half sinewave, 50Hz, T case = 80 oC 480 750 A A Symbol I T(AV) I T(RMS) TF708..B Fast Switching Thyristor Replaces March 1998 version, DS4276-2.2 DS4276-3.0 January 2000 |
