PSAC45W Characteristics

WWW.PHIHONG.COM

Input:

AC Input Voltage Rating

120-240V AC

AC Input Voltage Range

89-270V AC

AC Input Frequency

47-63Hz

Input Current

1.2A (RMS) Maximum at 120V AC

Leakage Current

250uA maximum

Inrush Current

120A max. at 120V AC and max load

(Ambient 25°C cold start

Input Power Saving

0.3W maximum at nominal input

Output:

Efficiency

Meets Level V Efficiency Requirements

87.7% minimum

Environmental:

Temperature

Operation

0 to 40°C

Non-operation

-20 to 70°C

Operating Humidity

5 to 90%

EMC

FCC Class B

EN55022 Class B

Immunity

IEC61000-4-2

IEC61000-4-3

IEC61000-4-4

IEC61000-4-5

IEC61000-4-6

IEC61000-4-8

IEC61000-4-11

EN61000-3-2

Over-Voltage Protection

Auto-restart

Over-Current Protection

Auto-restart

Short-Circuit Protection

Protected against short circuit – Output can be

shorted permanently without damage

Dielectric Withstand (Hi-pot) Test

Primary to Secondary: 3000V AC, 10mA for 1 minute

Insulation Resistance

Primary to secondary: >7M ohm 500V DC

DC Output Connector

Center Positive Barrel (10mm x 5.5mm x 2.1mm)

DC Cord

1500mm ± 50

Dimension Diagram Unit: mm (inch)
