Data Sheet

AD5543/AD5553

Rev. F | Page 5 of 20

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

VDD to GND

−0.3 V to +8 V

VREF to GND

−18 V to +18 V

Logic Inputs to GND

−0.3 V to +8 V

V(IOUT) to GND

−0.3 V to VDD + 0.3 V

Input Current to Any Pin Except Supplies

±50 mA

Package Power Dissipation

(TJ Max − TA )/θJA

Thermal Resistance, θJA

8-Lead Surface Mount (MSOP)

150°C/W

8-Lead Surface Mount (SOIC)

100°C/W

Maximum Junction Temperature (TJ Max)

150°C

Operating Temperature Range

Model B and Model C

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Lead Temperature

R-8, RM-8 (Vapor Phase, 60 sec)

215°C

R-8, RM-8 (Infrared, 15 sec)

220°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

ESD CAUTION
