3 / 4 page  SMD Type www.kexin.com.cn 3 Transistors PNP Transistors 2SA1514K ■ Typical Characterisitics -0.1 -1 -10 -0.1 -1 -10 -100 Ta= －40ºC 25ºC 100ºC IC / IB = 10/1 -0.01 -0.1 -1 -10 -0.1 -1 -10 -100 IC / IB = 10/1 Ta=100ºC 25ºC － 40ºC -0.01 -0.1 -1 -10 -0.1 -1 -10 -100 Ta=25ºC IC / IB =50/1 20/1 10/1 Fig.5 Collector-Emitter Saturation Voltage vs. Collector Current (I) COLLECTOR CURRENT : IC [mA] Fig.6 Collector-Emitter Saturation Voltage vs. Collector Current (II) COLLECTOR CURRENT : IC [mA] Fig.7 Base-Emitter Saturation Voltage vs. Collector Current COLLECTOR CURRENT : IC [mA] Fig.8 Gain Bandwidth Product vs. Emitter Current EMITTER CURRENT :IE [mA] |
|
|
