FDA series

Automotive fully-digital

audio amplifiers

www.st.com/car-radio

ST has launched a complete

family of PWM digital-input power

amplifiers to offer new ways of

thinking about audio power

amplification in automotive

applications.

ST’s environment-friendly

approach translates into class D

efficiency, start-stop compliancy

and a new feedback concept

that significantly reduces

the cost and size of external

components and grants

outstanding EMI performances.

Cool, very powerful and with very

low radiated emissions, the FDA

series are the perfect amplifiers

for new generation head units

and boosters.

Key features

•

ClassDefficiency

•

I²SorTDMdigitalinput

•

Veryhighoutputpowercapability

•

IntegratedD/Aconverter

•

Automotive-gradeEMI/EMC

performances

•

Low-passoutputfilterincludedinthe

feedbackloop

•

6Voperation

•

I²Cdiagnostics

•

Fullfaultprotection

•

Integratedstep-updriver(FDA4100LVand

FDA2100LV)

Key benefits

•

Highnoise-injectionimmunity(for

example,toGSM)thankstothedigital

input

•

Noneedfordigital-to-analogconverter

andinputfilters

•

Verylowpowerdissipation

•

Noneedforexternalsolutionstoplay

musicduringcrankswith

start-stopengines

•

Theinnovativefeedbackloopavoidsthe

useofcomplicatedexternalnetworksto

reduceradiatedemissionsandallows

theuseofaverylowcostandsmallsize

outputfilter

targeted applications

•

Headunits

•

Boosters

•

Infotainmentsystems
