07.10.2014

LED490-series

1 of 3

LED490-series

TECHNICAL DATA

Visible LED

InGaN

LED490-series are InGaN LEDs mounted on a lead frame and encapsulated in various types of

epoxy lens, which offers different design settings.

On forward bias, it emits a band of visible light at a peak wavelength of 490 nm.

Specifications

• Structure: InGaN

• Peak Wavelength: typ. 490 nm

• Optical Ouput Power: typ. 12 mW

• Resin Material: Epoxy resin

• Solder: Lead free

Type

Symbol

Value

Unit

Power Dissipation

200

mW

Forward Current

50

mA

Reverse Voltage

5

V

Operating Temperature

-40 … +85

°C

Storage Temperature

-40 … +100

°C

Soldering Temperature (for 5 sec.)

265

°C

Item

Symbol

Condition

Min.

Typ.

Max.

Unit

Forward Voltage

-

3.3

4.0

V

Reverse Current

-

-

10

µA

Radiated Power

-

12

-

mW

Peak Wavelength

λ

P

480

490

500

nm

Half Width

Δλ

-

30

-

nm
