21.11.2011

LED535-series

1 of 8

LED535-series

TECHNICAL DATA

Visible LED

InGaN

LED535-series are InGaN LEDs mounted on a lead frame and encapsulated in various types of

epoxy lens, which offers different design settings.

On forward bias, it emits a high power radiation of typical 4.0 mW at a peak wavelength at

535 nm.

Specifications

• Structure: InGaN

• Peak Wavelength: typ. 535 nm

• Optical Ouput Power: typ. 4.0 mW

• Resin Material: Epoxy resin

• Solder: Lead free

Type

Symbol

Value

Unit

Power Dissipation

200

mW

Forward Current

50

mA

Reverse Voltage

5

V

Operating Temperature

-30 … +85

°C

Storage Temperature

-40 … +100

°C

Soldering Temperature (for 5 sec.)

265

°C

Item

Symbol

Condition

Min.

Typ.

Max.

Unit

Forward Voltage

-

3.2

4.0

V

Reverse Current

-

-

10

µA

Radiated Power

-

4.0

-

mW

Peak Wavelength

λ

P

525

535

545

nm

Half Width

Δλ

-

35

-

nm
