21.11.2011

LED545-series

2 of 8

Type

Viewing

Half Angle

Outer

Dimension

Dimension

Figure

[Unit: mcd]

[Unit: mW/sr]

Typ.

Typ.

LED545-01

±8°

20000

25

Ø 5

1

LED545-02

±5°

21000

27

Ø 5

2

LED545-03

±10°

21000

27

Ø 5

3

LED545-04

±20°

8000

12

Ø 5

4

LED545-05

±50°

1400

1.2

Ø 5

5

LED545-06

±4°

36000

40

Ø 5

6

LED545-09

±25° (long)

12000

15

Ø 5

7

±10° (short)

Oval

LED545-46

Ø 5

8

LED545-41

±14°

14000

9

Ø 4

9

LED545-42

±20°

7000

9

Ø 4

10

LED545-31

Ø 3

11

LED545-33

±13°

10000

15

Ø 3

12

LED545-34

Ø 3

13

LED545-36

±25°

3500

5

Ø 3

14

* Radiant Power is measured by S3584-08

* Brightness is measured by TekTronix J-16

The above specifications are for reference purpose only and subjected to change without prior notice.

Outer Dimensions

Figure-1 Ø 5Mold (Type 01)

Figure-2 Ø 5Mold (Type 02)

Figure-3 Ø 5Mold (Type 03)

Figure-4 Ø 5Mold (Type 04)
