 2 / 9 page
background image
18.08.2010
led830_series.doc
2 of 9
● Characteristics of Radiant Intensity [Ta=25°C]
Radiant Intensity IF= 50mA [mW/sr]
Type
Viewing
Half Angle
Minimum
Typical
Maximum
Outer
Dimension
Dimension
Figure
LED830-
01AU
± 10°
100
Ø 5
1
LED830-
02AU
± 7°
100
Ø 5
2
LED830-
03AU
± 10°
110
Ø 5
3
LED830-
04AU
± 20°
45
Ø 5
4
LED830-
05AU
± 40°
12
Ø 5
5
LED830-
06AU
± 7°
130
Ø 5
6
± 25°
(Long)
Ø 5
LED830-
09AU
± 10°
(Short)
60
Oval
7
LED830-
46AU
Ø 5
8
LED830-
41AU
± 16°
75
Ø 4
9
LED830-
42AU
± 23°
40
Ø 4
10
LED830-
31AU
Ø 3
11
LED830-
33AU
± 18°
45
Ø 3
12
LED830-
34AU
Ø 3
13
LED830-
36AU
± 33°
200
Ø 3
14
► Total Radiant Power is measured by Photodyne #500.
