QBLP612 Series
Side View 0802 LED
------------------------------------------------------------------------------------------------------------------------------------------
Product: QBLP612 Series
Date: September 16, 2014
Page 4 of 12
Version# 1.0
Electrical / Optical Characteristic (Ta=25
oC)
Product
Color
IF(mA)
VF (V)
λD (nm)
IV (mcd)
Typ.
Max.
Min.
Typ.
Max.
Min.
Typ.
QBLP612-R
Red
20
2.0
2.5
625
630
635
40
70
QBLP612-AG
Yellow Green
20
2.0
2.5
565
570
576
25
40
QBLP612-IG
True Green
20
3.2
3.7
520
525
530
250
430
QBLP612-IW-
CW
Cool White
20
3.2
3.7
X=0.25
Y=0.24
-
X=0.33
Y=0.34
160
320
Absolute Maximum Rating
Material
Pd (mW)
IF (mA)
IFP (mA)*
VR (V)
TOP (
oC)
TST (
oC)
TSOL (
oC)**
AlInGaP
75
30
125
5
-40 to +80
-40 to +85
260
InGaN
111
30
125
5
-40 to +80
-40 to +85
260
*Duty 1/8 @ 1kHz
**IR Reflow for no more than 10 sec @ 260
oC
Forward Voltage VF for AlInGaP @ IF=20mA
Bin
Min.
Max.
Unit
□
1.7
2.5
V
Forward Voltage VF for InGaN @ IF=20mA
Bin
Min.
Max.
Unit
f
2.8
3.1
V
g
3.1
3.4
h
3.4
3.7
