QBLP674-XX Series

3014 PLCC2 LED

-----------------------------------------------------------------------------------------------------------------------------------------

Product: QBLP674-XX Series

Date: August 29, 2014

Page 3 of 12

Version# 2.3

Introduction

Feature:

 Package in tape and reel

 Ultra bright reflector type 3014 PLCC2 LED

 InGaN technology for IB/IG

 AlInGaP technology for R/AG/Y/O/S

 120 degree viewing angle

Description:

These ultra bright reflector type 3014 PLCC2 LEDs have

a height profile of 0.75mm. Combination of high

brightness output and robust package, these LEDs are

ideal for architecture lighting, status indication, and

industrial equipment lighting applications.

Application:

 Status indication

 Industrial equipment backlighting

 Architecture lighting

Certification & Compliance:

 TS16949

 ISO9001

 RoHS Compliant

Dimension:

Units: mm / tolerance = +/-0.1mm
