CONN005-R58 Datasheet(PDF) 1 Page - List of Unclassifed Manufacturers

Part # CONN005-R58
Description  N FEMALE BULKHEAD MOUNT CABLE END CRIMP FOR RG58 CABLE
PDF  1 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Manufacturer  ETC2 [List of Unclassifed Manufacturers]
Direct Link
Logo ETC2 - List of Unclassifed Manufacturers

CONN005-R58 Datasheet(HTML) 1 Page - List of Unclassifed Manufacturers

  CONN005-R58 Datasheet HTML 1Page - List of Unclassifed Manufacturers
Zoom Inzoom in Zoom Outzoom out
 1 / 1 page
background image
A
B
C
D
4
3
2
1
D
C
B
A
1
2
4
3
N FEMALE BULKHEAD MOUNT
CABLE END CRIMP FOR RG58 CABLE
0.276
(7.00)
0.315
(8.00)
RECOMMENDED CABLE STRIPPING DIMENSIONS
0.177
(4.50)
RG-58 Cable
Description
Material
Finish
Nut
Washer
Body
Nickel
Nickel
Nickel
Brass
Brass
Brass
Socket
Gold
Brass
Crimp Ring
Nickel
Brass
CONNECTOR CITY
159 ORT LANE
MERLIN, OR 97532
PH (541)-471-6256
FAX (541)-471-6251
Date:
Sheet 1 of 1
Revision:
Title
Part No.
Dimensions:
CONN005-R58
1.0
INCHES (mm)
2/11/2008
RECOMMENDED
MOUNTING HOLE
Ø0.634
(16.10)
0.571
(14.50)
1.
Solder the socket to the center conductor.
2.
Insert the socket, center conductor, and insulator into the body.
3.
Wrap the braid around the tail of the body and crimp the ring with a
hex crimp tool labeled for use with RG-58 cable.
CONN005-R58 ASSEMBLY INSTRUCTIONS
Insulation
N/A
Teflon
O Ring
N/A
SI Rubber
0.110
(2.80)
5/8-24UNEF-2B
THREADS
H19
NUT
Ø0.866
(22.00)
0.020
(0.50)
WASHER
0.500
(12.70)
Ø0.252
(6.40)
CRIMP RING
0.673
(17.10)
∅0.083
(2.10)
PIN
∅0.119
(3.02)
5/8-24UNEF-2A THREADS
SIDE VIEW
∅0.531
(13.50)
∅0.177
(4.50)
FLAT 0.528 x2
(13.40)
0.929
(23.60)
1.410
(35.70)
∅0.862
(21.90)
