U74AHC1G66

CMOS IC

www.unisonic.com.tw

1 of 7

QW-R502-098.D

BILATERAL SWITCH



DESCRIPTION

The UTC U74AHC1G66 is an analog switch which transmits

signals from pin(Y or Z) to pin (Z or Y) with an active HIGH enable

input pin (E). When pin E is LOW, the switch is turned off.



FEATURES

* Operation voltage range: 2~5.5V

* Low power dissipation

* Very low ON-resistance: 26Ω (typ.) at VCC=3.0V

16Ω (typ.) at VCC=4.5V

14Ω (typ.) at VCC=5.5V



ORDERING INFORMATION

Ordering Number

Package

Packing

U74LVC1G34G-AF5-R

SOT-25

Tape Reel

U74LVC1G34G-AL5-R

SOT-353

Tape Reel



MARKING

Similar Part No. - U74LVC1G34G-AF5-R
