U74LVC1G14

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

3 of 5

www.unisonic.com.tw

QW-R502-081.H



PARAMETER

SYMBOL

TEST CONDITIONS

RATINGS

UNIT

Supply Voltage

-0.5~6.5

V

Input Voltage

-0.5~6.5

V

Output in the high or low state

V

Output Voltage

Output in the power-off state

-0.5~6.5

V

Current

±100

mA

Continuous Output Current

±50

mA

Input Clamp Current

-50

mA

Output Clamp Current

-50

mA

Storage Temperature Range

-65 ~+150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

SOT-23-5

280

SOT-25

230

Junction to Ambient

SOT-353

350

°C/W



RECOMMENDED OPERATING CONDITIONS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Operating

1.65

5.5

V

Supply Voltage

Data retention only

1.5

V

Input Voltage

0

5.5

V

Output Voltage

High or low state

0

V

20

ns/V

10

ns/V

Input Transition Rise or Fall

Rate

t/v

5

ns/V

Operating Temperature

-40

125

°C



ELECTRICAL CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

0.79

1.16

V

1.11

1.56

V

1.5

1.87

V

2.16

2.74

V

Positive-Going Input Threshold

Voltage

2.61

3.33

V

0.39

0.62

V

0.58

0.87

V

0.84

1.14

V

1.41

1.79

V

Negative-Going Input

Threshold Voltage

1.87

2.29

V

0.37

0.62

V

0.48

0.77

V

0.56

0.87

V

0.71

1.04

V

△

0.71

1.11

V
