ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

-0.5 ~ +6.5

V

Input Voltage

-0.5 ~ +6.5

V

Output Voltage

Output in the high or low state

-0.5 ~ +6.5

V

Output in the high-impedance or

power-off state

-0.5 ~ +6.5

V

±100

mA

50

mA

-50

mA

-50

mA

Operating Temperature

-40~+85

°C

Storage Temperature Range

-65 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

RECOMMENDED OPERATING CONDITIONS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Supply Voltage

Operating

1.65

5.5

V

Data retention only

1.5

V

Input Voltage

0

5.5

V

Output Voltage

active mode

0

V

high-impedance mode

0

5.5

V

Low-level Output Current

4

mA

8

mA

16

mA

24

mA

32

mA

Input Transition Rise or Fall

Rate

Δt/ΔV

20

ns/V

10

ns/V

5

ns/V
