2 / 4 page ![]() UT2311 Power MOSFET UNISONICTECHNOLOGIESCO.,LTD 2 of 4 www.unisonic.com.tw QW-R502-365.D ABSOLUTE MAXIMUM RATINGS (TA = 25°C, unless otherwise noted) PARAMETER SYMBOL RATINGS UNIT Drain-Source Voltage VDSS -20 V Gate-Source Voltage VGSS ±8 V Continuous Drain Current ID -4 A Pulsed Drain Current IDM -20 A Power Dissipation (TA=25°C) (Note 2) PD 1.25 W Junction Temperature TJ +150 °C Storage Temperature TSTG -55 ~ +150 °C Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied. 2. Surface mounted on 1 in 2 copper pad of FR4 board. THERMAL DATA PARAMETER SYMBOL RATINGS UNIT Junction to Ambient (PCB mounted) θJA 100 °C/W Note: Surface Mounted on FR4 board t ≤ 5 sec. ELECTRICAL CHARACTERISTICS (TA = 25°C, unless otherwise specified) PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT OFF CHARACTERISTICS Drain-Source Breakdown Voltage BVDSS VGS =0V, ID =-250µA -20 V Drain-Source Leakage Current IDSS VDS =-16V,VGS =0V -1.0 µA Gate-Source Leakage Current IGSS VGS =±8V, VDS =0V ±100 nA ON CHARACTERISTICS Gate Threshold Voltage VGS(TH) VDS =VGS, ID =-250µA -0.45 V VGS =-4.5V, ID =-4.0 A 45 55 mΩ Static Drain-Source On-State Resistance RDS(ON) VGS =-2.5V, ID =-2.5 A 75 85 mΩ On-State Drain Current ID(ON) VDS ≥ -10V, VGS =-4.5V -6 A DYNAMIC PARAMETERS b Input Capacitance CISS 970 pF Output Capacitance COSS 485 pF Reverse Transfer Capacitance CRSS VDS =-6V, VGS =0 V, f =1.0MHz 160 pF SWITCHING PARAMETERS b Turn-ON Delay Time tD(ON) 18 ns Turn-ON Rise Time tR 45 ns Turn-OFF Delay Time tD(OFF) 95 ns Turn-OFF Fall-Time tF VDD =-4V, VGEN =-4.5V, ID =-1A RL =4Ω, RG =6Ω 65 ns Total Gate Charge QG 8.5 12 nC Gate Source Charge QGS 1.5 nC Gate Drain Charge QGD VGS =-4.5V, VDS =-6V, ID =-4.0A 2.1 nC SOURCE- DRAIN DIODE RATINGS AND CHARACTERISTICS Drain-Source Diode Forward Voltage VSD VGS =0 V, IS =-1.6A, -0.8 -1.2 V Maximum Continuous Drain-Source Diode Forward Current IS -1.6 A Note: Pulse test; pulse width ≤ 300μs, duty cycle ≤ 2%. |
|
|
