I

www.glenair.com

E-Mail:sales@glenair.com

GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912

I-3

U.S. CAGE Code 06324

Printed in U.S.A.

181-059

M29504/17 Type

GFOCA Fiber Optic Dummy Terminus

Material and Finish

Terminus body: Stainless steel/passivate

Seal: Elastomeric Rubber

Notes

Terminus is designed to meet the general requirements of MIL-PRF-29504/17 (Draft)

GFOCA

Part Number

181-059

GFOCA M29504/17 Type Dummy Terminus

(Ø.218)

(Ø.090)

Terminus body

Seal

Ø.090

Max

Ø.218

Max

.855 Max

.60

M29504/17 Type gFOCa fiber optic dummy terminus
