TECHNICAL DATA SHEET

RP BNC Male Connector Solder Attachment 4 Hole Flange Solder Cup Terminal, .531 inch Hole Spacing

Configuration

Connector

BNC Male Reverse Polarity

Connector Interface Type

Solder Cup

Cable Attachment Method (Shield/Contact)

Solder

Body Style

Straight

Mount Method

4 Hole Flange

Electrical Specifications

Impedance, Ohms

50

Mechanical Specifications

Size

Length, in [mm]

1.215 [30.86]

Width/Dia., in [mm]

0.75 [19.05]

Height, in [mm]

0.75 [19.05]

.

Weight, lbs [g]

0.041 [18.6]

Connector

Type

BNC Male Reverse Polarity

Contact Material and Plating

Gold

Coupling Nut Material and Plating

Brass, Nickel

Body Material and Plating

Brass, Nickel

Dielectric Type

PTFE

RoHS Compliant

Yes

Plotted and Other Data

Notes:

Values at 25 °C, sea level

RP BNC Male Connector Solder Attachment 4 Hole Flange Solder Cup Terminal, .531 inch Hole Spacing from Pasternack

Enterprises has same day shipment for domestic and International orders. Our RF, microwave and fiber optic products maintain

a 99% availability and are part of the broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: RP BNC Male Connector Solder Attachment 4 Hole Flange Solder Cup Terminal, .531 inch Hole

Spacing PE4762
