TECHNICAL DATA SHEET

75 Ohm BNC Male Right Angle Connector Clamp/Solder Attachment For RG59

Configuration

Connector

BNC Male

Connector Specification

MIL-STD-348

Connector Interface Type

RG59

Cable Attachment Method (Shield/Contact)

Clamp/Solder

Body Style

Right Angle

Electrical Specifications

Frequency Range, GHz

DC to 2

Impedance, Ohms

75

Maximum Operating Voltage, Volts

500

Dielectric Withstanding Voltage, Vrms

1,500

Mechanical Specifications

Temperature

Operating Range, deg C

-65 to +165

Size

Length, in [mm]

1.48 [37.59]

Width/Dia., in [mm]

0.57 [14.48]

Height, in [mm]

1.032 [26.21]

.

Weight, lbs [g]

0.068 [30.84]

Connector

Type

BNC Male

Contact Material and Plating

Brass/Beryllium Copper, Silver

Coupling Nut Material and Plating

Brass, Nickel

Body Material and Plating

Brass, Nickel

Dielectric Type

PTFE

RoHS Compliant

Yes

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: 75 Ohm BNC Male Right Angle Connector Clamp/Solder Attachment For RG59 PE4607

PE4607

PE4607 REV 01

75 Ohm BNC Male Right Angle Connector

Clamp/Solder Attachment For RG59
